What is a Backbone Network?

A backbone network is a network that uses high-capacity connectivity equipment as the main link connecting all of the network nodes. The network frequently consists of various cabling, switch, bridge, router, and gateway components. Instead of connecting directly to the backbone, individual nodes connect through their LANs, ISPs, or larger organizational infrastructures.

The concept of a backbone, which is sometimes described as a network of wires acting as a data superhighway, hasn't changed, but the method of execution has. A backbone's capacity is projected to exceed that of the networks it supports.

Why do we need a backbone network? The backbone networks of a computer network are crucial elements that support the network's stability. The backbone's role is to provide the connections necessary for the network's numerous components to cooperate and communicate while preserving each component's autonomy. With this approach, it could be possible to connect numerous networks to administer specific duties and share specific types of data while preserving the autonomy of each network attached to the backbone.

How do backbone networks work? Every device in a backbone network is linked to one or more other devices by high-capacity links, like fiber optic cables or satellite links. High-speed data transmission between devices across these lines enables the backbone network to handle heavy traffic loads.

Routing protocols are used by devices to exchange network knowledge and choose the optimal path for data to take when moving between different networks to route traffic inside the backbone network. The quickest and most effective path between two sites is determined by routing protocols using algorithms that consider link capacity, distance, and network congestion.

The connectivity may only cover a small portion of a building's interior or its immediate surroundings, or it may cover a wide area. The backbone's capacity is much higher than that of the several networks that are connected to it.

Types of backbone networks

There are different types of backbone networks −

Distributed (Bus backbone)

The Bus Backbone manages the Bus Topology and any protocols, such as 10Base2 and 10Base5, that can be modified to work with the Bus Topology. It connects the numerous subnetworks on various floors, as its name implies. LANs connect every one of the building's numerous floors. To share resources and exchange data, they also build a star topology backbone that connects numerous LANs via a bus backbone.

The bridge prevents data from leaving the LAN terminal on the backbone. Let's imagine the terminal is exchanging data with a different LAN on the backbone bridge. Then, when the backbone bridge connects to the LAN, the data is created into a frame and sent to the bridge over the backbone. The frame is then sent to the destination LAN and terminal after that. Each backbone bridge maintains a table of LANs to help with information flow.

Collapsed backbone (Star backbone)

A backbone connecting numerous LANs or subnetworks is constructed using wiring hubs and switches in the star backbone. One switch connects each LAN to the others. It is hence often referred to as the "flipped backbone." The star backbone connects the LAN on each floor to the star backbone. The switch is the backbone of the star backbone. It is located in a particular structure area, like a computer or data center.

The switch sent a separate table flow to each floor of the LANs. Every LAN is configured in a star topology, with switches or hubs deployed in the same location as the backbone switch on each floor.

Serial backbone network

A single cable connected to a network extension forms the serial backbone, consisting of two or more networked devices, or nodes, connected in series. Despite being the most straightforward backbone architecture, it is rarely used for enterprise-level network topologies due to its high susceptibility to mistakes and system failures. Since there are no other routes for data transfer, the entire network may be impacted if a link between routers breaks. As a result, only very small network installations utilize this type.

Simple distributed backbone network

The distributed backbone network comprises a hierarchical arrangement of objects with various connecting possibilities. For example, intermediary devices that connect to the backbone router and gateway devices are created when numerous devices are linked to switches.

The distributed backbone network is more appropriate than the serial backbone network for connecting an entire organization. In addition, the network can be readily expanded and troubleshot since network layers are simple to create and operate.

Parallel backbone network

A parallel backbone, a variation of the collapsed backbone, is a term used to describe devices with more than one link between them. The high-level routers are linked to the network segments by several links. Greater speeds, improved fault tolerance, and ongoing network availability are all guaranteed by duplicate connections. These systems' rising costs are a reasonable drawback, given how much more cabling is required. Duplicate connections between all devices are unnecessary because installing a chosen parallel structure would significantly lower overall expenses and increase the number of ports accessible for the devices.

Uses of Backbone network

Connecting networks

Backbone networks connect networks throughout a city, region, or even the entire planet, as well as networks on a single campus or building. This makes it possible for various networks to share resources and exchange information.

Providing a high-capacity infrastructure

Backbone networks use high-capacity technology like fiber optic cables or satellite links to transfer data across great distances and are intended to be quick, dependable, and highly expandable. Because of this, they work effectively for applications that require a lot of bandwidth or data transfer.

Ensuring network availability

 Backbone networks frequently include redundant connections and take various precautions to ensure they are highly available and resilient to failures or disturbances. This makes it possible for the network to function even if one or more components fail, ensuring that data is supplied dependably and uninterruptedly.

Enabling communication between devices

Backbone networks offer the network infrastructure needed for connecting electronic devices like computers, phones, and other gadgets. This is necessary for programs like the Internet, which depend on devices being able to communicate and exchange information with one another.

Supporting critical infrastructure

Utility companies, transportation companies, and governmental organizations are among the critical infrastructure applications that employ backbone networks. They offer the connectivity necessary for these technologies to function properly and effectively.

‍
